Plasma cutter Lincoln Electric Tomahawk 30K

Lincoln Electric Tomahawk 30K is a portable plasma cutter perfect for field work. It is used, among others, in on-site maintenance, small construction sites, ventilation installations (HVAC), demolition works and rental. The cutter allows you to cut and grind materials up to 10 mm thick. The equipment will let you work with materials such as: carbon, low-alloy steel, aluminum, austenitic stainless steel, copper alloys, magnesium and others. The device is powered by a single-phase 230V 50Hz network. The source allows cutting current of 25A at 60% duty cycle and 30A at 100% duty cycle. It has a 16A fuse. The housing is made with IP23S protection level. The weight of the device is 18.5 kg and the dimensions are 385 x 215 x 480 mm.

The main advantages of the device includes:

• Ease of transport – thanks to the built-in compressor, the equipment allows work in the field where a source of compressed air is usually not available.
• Possibility of continuous control of parameters – especially useful when cutting materials of different thickness.
• Contact arc ignition does not require the use of high-frequency current.
• Fast re-ignition for faster cutting of mesh and expanded metal.
• Air flow adjustment from the front panel allows you to set the correct flow before the arc is ignited.
• Comfortable operation thanks to high durability of consumable parts and to the new electrode and nozzle design allows you to reduce costs in the long run.
• Increased safety – the Parts-in-Place system detects incorrect installation of consumable parts in the torch. Generator compatibility – works with Lincoln Electric’s Vantage when working in the field.

9. LED Signaling – Power Status: Diode LED. It lights up when the device is turned on and is connected to the network in the right way.

10. Device Thermal Overheating Signaling: Diode LED. It lights up when the device is overheated.

11. Correct Connection of the Handle: Diode LED. It lights up when the handle is connected incorrectly into the plasma holder slot or when the torch nozzle is not tightened to the holder.

12. Device Operation Signaling: Diode LED. It lights up when the device is working.

13. Manoflowmeter: Allows you to read the current air pressure.

14. Pressure Adjustment Knob: Allows you to adjust the air pressure.

15. Air source selection switch: IN COMPR Built-in compressor EXT AIR External air network

16. RUN/SET switch: Cutting is not possible in the “Set” position. SET Air test RUN Ready to cut

17. Cutting Current Regulator Knob: Potentiometer for adjusting the cutting current.

The set includes:

• Built-in compressor (also socket for an external compressed air source)

• Lincoln Electric LC30 hand torch with 4 m cable

• Compressed air reducer

• Built-in water separator

• Ground cable clamp and cable

• Replaceable wear parts

• Power cord
